Model
Mixing volume Design RPM
SDM-20
20L(AC 0.25kW)~450 RPM
SDM-60
50L(AC 0.25kW)~450 RPM
SDM-100
150L(AC 0.37kW)~450 RPM
SDM-150
700L(AC 0.75kW)~450 RPM
SDM-200
1500L(AC 1.5kW)~350 RPM
SDM-220
3000L(AC 2.2kW)~350 RPM
SDM-250
7000L(AC 4.0kW)~350 RPM
SDM-300
15000L(AC 5.5kW)~350 RPM
SDM-400
30000L(AC 7.5kW)~220 RPM
SDM-500
50000L(AC 11.0kW)~220 RPM
Specification
- Impeller
- Std.Material : Stainless Steel
- Surface Finish : Ra <0.38 μm
- Welding Plate
- Std.Material : Stainless Steel
- Surface Finish : Ra <0.38 μm
- Bearing
- Std.Material : Stainless Steel
- Surface Finish : Ra <0.38 μm
- Drive Unit
- Std.Material : Stainless Steel
- Surface Finish : Ra <0.38 μm
- ※ VFD 사용하여 속도 및 가/감속 제어가 필요합니다.
- ※ 특수 재질 사용 필요시 당사 문의 바랍니다.
